使用:將尼龍軟管按入接頭中即可，欲取出時，按住接頭旁邊之PUSH處，拉出即可。
特點:快速、便捷、方便、縮短施工時效。
|
型號 |
牙制 |
適用浪管 |
尺寸(mm) |
包裝 |
|||||
|
M牙規格(METRIC) |
|
(尼龍管) |
A(mm) |
B(mm) |
C(mm) |
D(mm) |
E(mm) |
F(mm) |
|
|
MB-02BF |
M12*1.5 |
PB-02 |
10 |
16.8 |
5.2 |
18.5 |
10 |
12 |
100PCS |
|
MB-0205BF |
M16*1.5 |
PB-02-05 |
13 |
19.8 |
6.8 |
23.7 |
10 |
16 |
100PCS |
|
MB-0205BF-A |
M20*1.5 |
PB-02-05 |
13 |
19.8 |
6.8 |
29 |
10 |
20 |
100PCS |
|
MB-03BF |
M16*1.5 |
PB-03 |
15.8 |
22.8 |
6.8 |
24 |
13 |
16 |
50PCS |
|
MB-03BF-A |
M20*1.5 |
PB-03 |
15.8 |
22.8 |
6.5 |
29 |
13 |
20 |
50PCS |
|
MB-03BF-A-L9 |
M20*1.5 |
PB-03 |
15.8 |
22.8 |
6.5 |
29 |
9 |
20 |
50PCS |
|
MB-0305BF |
M20*1.5 |
PB-03-05 |
17 |
30 |
6.5 |
29 |
13 |
20 |
50PCS |
|
MB-04BF |
M20*1.5 |
PB-04 |
21 |
30 |
6.5 |
29 |
13 |
20 |
50PCS |
|
MB-04BF-L20 |
M20*1.5 |
PB-04 |
21.2 |
30 |
6.8 |
29 |
20 |
20 |
50PCS |
|
MB-04BF-A |
M24*1.5 |
PB-04 |
21.2 |
30 |
6.5 |
29 |
13 |
24 |
50PCS |
|
MB-06BF |
M25*1.5 |
PB-06 |
28.5 |
37 |
7.5 |
36 |
13 |
25 |
50PCS |
|
MB-06BF-L20 |
M25*1.5 |
PB-04 |
28.5 |
37 |
7.5 |
36 |
20 |
25 |
50PCS |
|
MB-06BF-04 |
M25*1.5 |
PB-04 |
21.2 |
37 |
7.5 |
36 |
13 |
25 |
50PCS |
|
MB-06BF-04-L20 |
M25*1.5 |
PB-04 |
28.5 |
37 |
7.5 |
36 |
20 |
25 |
50PCS |
|
MB-10BF |
M32*1.5 |
PB-10 |
34.5 |
43.2 |
7.7 |
47.3 |
13 |
32 |
25PCS |
|
MB-10BF-L20 |
M32*1.5 |
PB-10 |
34.5 |
43.2 |
7.7 |
47.3 |
20 |
32 |
25PCS |
|
MB-10BF-A |
M36*2.0 |
PB-10 |
34.5 |
43.2 |
7.7 |
47.3 |
13 |
36 |
25PCS |
|
MB-10BF-06A |
M36*2.0 |
PB-06 |
28.5 |
43.2 |
7.7 |
47.3 |
13 |
36 |
25PCS |
|
MB-12BF |
M40*1.5 |
PB-12 |
42.5 |
52 |
8.2 |
59 |
15 |
40 |
20PCS |
|
MB-20BF |
M50*1.5 |
PB-20 |
54.5 |
63 |
9.2 |
69 |
15 |
50 |
10PCS |
|
MB-20BF-A |
M63*1.5 |
PB-20 |
54.5 |
63 |
8.5 |
82 |
15 |
63 |
10PCS |
|
PG牙規格(DIN) |
|
|
|
|
|
|
|
|
|
|
GB-02BF |
PG7 |
PB-20 |
10 |
16.8 |
5.5 |
18.5 |
10 |
12.5 |
100PCS |
|
GB-0205BF |
PG9 |
PB-02-05 |
13 |
19.8 |
5 |
21.3 |
10 |
15.2 |
100PCS |
|
GB-03BF |
PG11 |
PB-03 |
15.8 |
22.8 |
6 |
25 |
10 |
18.6 |
50PCS |
|
GB-03BF-A |
PG13.5 |
PB-03 |
15.8 |
22.8 |
6 |
27 |
13 |
20.4 |
50PCS |
|
GB-0305BF |
PG16 |
PB-03-05 |
17 |
30 |
6 |
27 |
13 |
20.4 |
50PCS |
|
GB-04BF |
PG16 |
PB-04 |
21.2 |
30 |
6.4 |
32 |
13 |
22.5 |
50PCS |
|
GB-06BF |
PG21 |
PB-06 |
28.5 |
37 |
7 |
39 |
13 |
28.3 |
50PCS |
|
GB-06BF-04 |
PG21 |
PB-04 |
21.2 |
37 |
7 |
39 |
13 |
28.3 |
50PCS |
|
GB-10BF |
PG29 |
PB-10 |
34.5 |
43.2 |
8 |
48 |
13 |
37 |
25PCS |
|
GB-12BF |
PG36 |
PB-12 |
42.5 |
52 |
8 |
59.2 |
12 |
47 |
20PCS |
|
GB-20BF |
PG42 |
PB-20 |
54.5 |
63 |
8.8 |
69 |
15 |
54 |
10PCS |
|
GB-20BF-A |
PG48 |
PB-20 |
54.5 |
63 |
9.2 |
77 |
15 |
59.3 |
10PCS |
|
PF牙規格(DIN) |
|
|
|
|
|
|
|
|
|
|
FB-02BF |
1/4" |
PB-02 |
10 |
16.8 |
5.5 |
18.5 |
10 |
13.157 |
100PCS |
|
FB-0205BF |
3/8" |
PB-02-05 |
13 |
19.8 |
5 |
21.3 |
10 |
16.662 |
100PCS |
|
FB-03BF |
3/8" |
PB-03 |
15.8 |
22.8 |
6 |
25 |
12 |
16.662 |
50PCS |
|
FB-03BF-A |
1/2" |
PB-03 |
15.8 |
22.8 |
6.1 |
29 |
12 |
20.955 |
50PCS |
|
FB-0305BF |
1/2" |
PB-03-05 |
17 |
30 |
6.1 |
29 |
12 |
20.955 |
50PCS |
|
FB-04BF |
1/2" |
PB-04 |
21.2 |
30 |
6.1 |
29 |
12 |
20.955 |
50PCS |
|
FB-06BF |
3/4" |
PB-06 |
28.5 |
37 |
7 |
40 |
14 |
26.441 |
50PCS |
|
FB-06BF-04 |
3/4" |
PB-04 |
21.2 |
37 |
7 |
40 |
14 |
26.441 |
50PCS |
|
FB-10BF |
1" |
PB-10 |
34.5 |
43.2 |
7 |
47 |
14 |
33.249 |
25PCS |
|
FB-12BF |
1 1/4" |
PB-12 |
42.5 |
52 |
8 |
57 |
18 |
41.91 |
20PCS |
|
FB-20BF |
2" |
PB-20 |
54.5 |
63 |
9 |
76.5 |
20 |
59.614 |
10PCS |
